Condition: Refurbished
Compeve SKU: 101000180513
Specification:
Form factor - 36 x 28 cm / 14.2 x 11 inches
Processor socket - Dual LGA 1366
CPU bus speed - QPI: Up to 6.4GT/second, depending on processor
Chipset - Intel 5520
Super I/O controller - SMSC SCH5327, Rev B
Memory Expansion Slots - 6 (3 per processor)
Memory Type Supported:
DDR3, UDIMM (Unbuffered), ECC: 1GB, 2GB, and 4GB
DDR3, RDIMM (Registered), ECC: 4GB and 8GB
Memory Modes - NUMA (Non-Uniform Memory Architecture), Memory Node Interleave
Memory Speed Supported - 800, 1066, & 1333MHz
Maximum Memory - Supports up to 48GB
PCI Express Connectors:
2 PCI Express x16 Gen2 graphics
1 PCI Express Gen2 (x8 mechanically, x4 electrically)
1 PCI Express Gen1 (x8 mechanically, x4 electrically)
PCI Connectors (5.0V) - 2 full length 33 MHz 32-Bit
Supported Drive Interfaces:
Integrated 6-channel SATA 3.0Gb/sec controller with RAID 0, 1, 5, 10 and NCQ. (Factory integrated RAID is Microsoft Windows only)
Integrated RAID:
Controller Broadcom 5764 PCI-E LAN Controller
Memory Integrated 48KB receive buffer and 8KB transmit
buffer
Data rates supported 10/100/1000 Mb/s
Compliance IEEE 802.3, 802.3AB and 802.3u compliant, 802.3x
flow control
Bus architecture PCIe 1.0a
Data path width X1
Data path speed 2.5Gbit per sec per direction transfer rate
Data transfer mode Bus-master DMA
Power requirement 1.0 watts @ +3.3V AUX supply
Boot ROM support Yes
Network transfer rate 10BASE-T (half-duplex) 10 Mb/s
10BASE-T (full-duplex) 20 Mb/s
100BASE-TX (half-duplex) 100 Mb/s
100BASE-TX (full-duplex) 200 Mb/s
1000BASE-T (full-duplex) 2000 Mb/s
USB connectors:
Rear - 6
Front - 3
HD Integrated Audio:
High Definition Integrated Realtek ALC262 Audio with Line in, Line Out, Microphone, Headphone
Line-in, Line-out, Mic-in x2, and Headphone jacks
