| APC AP7830 Rack PDU Metered Zero U 20A,120V, 24 Outputs NEMA 5-20R Power Distribution Strip Rack Mountable |
| | |
| Manufacturer | APC |
| Model number | AP7830 |
| SKU | UPSD035 #676_70 |
| | |
| Features |
| Toolless Rack Mounting Capabilities | Server cases do not require additional tools to mount into NetShelter Enclosures, which allows the users to quickly and easily mount units in the rear of the enclosure. |
| Vertical Mounting Capabilities | Easily mounts vertically in racks or enclosures and occupies zero U of valuable rack space, which allows more equipment in the rack. Units that mount vertically are optimized to fit in a NetShelter enclosures. |
| | |
| Specifications |
| Type | Metered |
| Color | Black |
| Output Voltage | 120V |
| Output Watts (VA) | 1920 VA |
| Output Connector(s) | (24) NEMA 5-20R |
| Input Voltage | 100V, 120V |
| Input Frequency | 50/60 Hz |
| Maximum Input Current | 20A |
| Regulatory Derated Input Current | 16A |
| Input Connector(s) | NEMA L5-20P |
| Cord Length | 10 ft |
| Load Capacity | 1920 VA |
| Dimmensions | 63.75 x 2.19 x 1.73 inches |
| Weight | 15 lbs (6.82 kg) |
| | |
| Package |
| Condition | Refurbished |
| Contents | PDU, Mounting brackets, Toolless Mounting Kit, User Manual. |
| Warranty | 30 Days |
| | |
