DESCRIPTION

PNY Nvidia Quadro K4000 SDI 3GB GDDR5 PCIe 3.0 x16 GPU Professional Graphics Card VCQK4000SDI-PB

Manufacturer

PNY

Model number

Quadro K4000SDI

Part number

VCQK4000SDI-PB

SKU

K4200SDI

Description

With the NVIDIA Quadro K4000 SDI you can count on superior interaction when utilizing sophisticated virtual sets, augmented reality broadcast solutions, or rendering richer scene details and effects for video, film, or broadcast production.

Offering 3GB of GDDR5 graphics memory, 768 NVIDIA CUDA™ parallel processing cores and built on the latest NVIDIA Kepler™ architecture, the NVIDIA Quadro 4000K SDI delivers excellent performance across a broad range of broadcast, video and film pre- and post-production applications that require the compositing of 3D or other computer generated graphics in real-time with 2K, HD and SD video.

Specifications

CUDA Cores	768
GPU Memory	3GB GDDR5
Memory Interface	192-bit
Memory Bandwidth	134GB/s
System Interface	PCI Express 2.0 x16
SDI Output System Interface	Any available slot
K4000 Max Power	80W
K4000 Idle Power	18W
SDI Output Maximum Power	7 W
SDI Input Maximum Power	20 W
Energy Star Enabling	Yes
K4000 Thermal Solution	Ultra-quiet active fansink
SDI Output Thermal Solution	Passive
K4000 Dimensions	4.376 H x 9.50 L, Single Slot, Full Height
SDI Output Dimensions	3.875 H x 6.60 L Single Slot
K4000 Display Connectors	DVI-I DL + DP 1.2 + DP 1.2 + Stereo
DisplayPort 1.2	Yes
DisplayPort with Audio	Yes
DVI-D SL connectors	Yes, via included adapters
VGA connector	Yes, via included adapter
Number of Displays Supported	3
SDI Output Connectors	3 BNC (SDI Fill, SDI Key, Genlock)
Maximum DP 1.2 Resolution	3840 x 2160 at 60Hz (direct connect)
Maximum DVI-I DL Resolution	2560 x 1600 at 60Hz
Maximum DVI-I SL Resolution	1920 x 1200 at 60Hz
Maximum VGA Resolution	2048 x 1536 at 85Hz
HDCP Support	Yes
Professional 3D Support	Yes, via included stereo connector bracket
Graphics APIs	Shader Model 5.0, OpenGL 4.3, DirectX 11
Compute APIs	CUDA, DirectCompute, OpenCL
NVIEW	Yes
NVIDIA 3D Vision and 3D Vision Pro	Yes


Minimum System Requirements	Windows^® 8, 7, Vista, XP SP3, Linux^®, or Solaris^® PCIe x16 expansion slot 1GB or more of system memory, 2GB recommended 200MB of available disk space for full driver installation Blu-ray or DVD-ROM drive DisplayPort, DVI, or VGA compatible display(s)
