3M Heat Shrink Tubing Thin Wall Clear 1"x50' FP-301 80-6107-5261-2

3M Heat Shrink Tubing Thin Wall Clear 1"x50' FP-301 80-6107-5261-2

Condition New

Compeve SKU 201400100201

Specifications

Additional Flammability Rating  23053/5 class1

Applicable SAE-AMS-DTL-23053 Specifications 23053/5 class 1

Application Specifications  ABS

Assortment Kits Yes

Brands  3M

Dielectric Strength 900 V/mil

Elongation  175 %, 175 Decibel, 400 %, 400 Decibel

Flammability Rating UL 224 All Tubing Flame Test, No Flame Rating

Heat Shrink Type  Heat Shrink Tubing Kits, Single-Wall Polyolefin Heat Shrink Tubing

Material  Polyolefin, Flexible Polyolefin

Maximum Operating Temperature (Celsius) 135 ℃

Maximum Operating Temperature (Fahrenheit)  275 ℉

Minimum Shrink Temperature (Celsius)  100 ℃

Non-Corrosive Yes

Operating Temperature (Celsius) -55 to 135 Degrees Celsius

Operating Temperature (Fahrenheit)  -67 °F to 275 °F

Operating Temperature Range (Celsius) -55 °C to +135 °C, -55 °C to 135 °C

Operating Temperature Range (Fahrenheit)  -67 °F to 275 °F

Product Color Transparent

Product Form  48 in (1.22 m) sticks, 48 in (1.22 m) sticks with header label, 6 in (15.24 cm) pieces, Tube, Stick, Spool

Product Type  Single (Thin) Wall Tubing

Recovered Wall Thickness  0.025 in

Shrink Ratio  0.0840277777777778

Tensile Strength (Imperial) 2400 Pound-Force Per Square Inch

Tubing Type Single (Thin) Wall, Single Wall (Thin)

UL Approval Yes

UL Bug Temperature (Celsius)  125 Degrees Celsius

UL Bug Temperature (Fahrenheit) 257 Degrees Fahrenheit

UL Bug Voltage  600 Volt

UL File Number  E-39100
