HP XW8200 Workstation PC 1x 2.8GHz/4GB RAM/80GB/NVS 290 Video

HP XW8200 Workstation PC 1x 2.8GHz/4GB RAM/80GB/NVS 290 Video

Price :
Starting at: $1,550.00  $1,390.00
Save: 10% off


Add to Cart:
  • SKU: xw8200_front_4monitors
  • ISBN: 882780210455
  • Model: XW8200
  • Shipping Weight: 49lbs
  • 8 Units in Stock
  • Manufactured by: HP


HP XW8200 Workstation
Dual Intel Xeon 2.8GHz / 4GB RAM
80GB HDD / Quadro nVidia 440 NVS Graphics Card
Top-Of-The-Line Workstation, Extreme power, Quiet Design

Manufacturer: HP
Product Line #: HP XW8200 workstation


Socket: Dual 604
Chipset: Intel E7525
Supported CPU's: Single or dual Xeon (800Mhz FSB)
Memory: 8 slots, up to 16GB - PC2-3200 ECC REG
Networking: Integrated Gigabit Ethernet
Slots: PCI Express x16 ( 1 )
PCI Express x8 ( 1 )
PCI ( 2 )
PCI-X / 100 MHz ( 1 )
PCI-X / 133 MHz ( 1 )
Controllers: Intel Integrated 82801ER (ICH5)
UltraATA-133 ( 2 )
LSI Logic® Integrated 53C1030 , Ultra320 SCSI ( 2 ) (68-PIN)
SATA ( 2 )
Ports: 6 x Hi-Speed USB (2 additional at the front - total 8 USB)
1 x Serial - RS-232 - 9 pin D-Sub (DB-9),
1 x Parallel - IEEE 1284 (EPP/ECP) - 25 pin D-Sub (DB-25)
1 x Keyboard - Generic - 6 pin mini-DIN (PS/2 style)
1 x Mouse - Generic - 6 pin mini-DIN (PS/2 style)
1 x Network - Ethernet 10Base-T/100Base-TX/1000Base-T - RJ-45
1 x Audio - Line-in - Mini-phone stereo 3.5 mm
1 x Audio - Line-out - Mini-phone stereo 3.5 mm (+1 at the front)
1 x Microphone - Input - Mini-phone stereo 3.5 mm (+1 at the front))
1 x IEEE 1394 FireWire (1 additional at the front - total 2 FireWire)

Power Supply:

Power Supply: Delta Electronics DPS-600NB A - 600 Watt

Hard drives:

Compatible HDD's: SCSI, SATA or IDE


  • HP XW8200 Workstation 8200 Case
  • Dual Xeon Motherboard
  • Dual Intel Xeon 2.8GHz Processors
  • 80GB Hard Drive. Operating system is not installed
  • Quad nVidia 440 NVS Video Card, PCI-E x16, 256MB
  • 600 Watt Power Supply
  • CD-ROM Drive
  • 2 Heat Sink assemblies with Fans
  • 2 Hard drive mounting rails
  • Internal Cables
  • Case Fan
  • 4GB Ram
  • Internal Speaker
  • Video card bracket
  • Case keys
  • OS: Windows 7 Pro 64-bit
  • Power Cord
Condition: Refurbished - Perfect working condition, case may have some scratches
Warranty: 30 days


Top-of-the-line Intel®-based personal workstation.
Satisfy your insatiable demand for performance and

Combining the highest processing and I/O power from
Intel with the latest graphics technology from leading
graphics providers, the HP xw8200 Workstation delivers
dual-processing performance, large computational and
visualization capacity, expandability and HP’s renowned
reliability. A broad range of ISV-certified 3D and 2D PCI
Express (PCIe) graphics solutions are available, along
with operating system choices to best fit your
requirements. Supporting Extended Memory 64
Technology (EM64T)i, the HP xw8200 Workstation is
engineered to meet your present and future business
Get the highest performance Intel technology available
on a personal workstation

Intel’s E7525 high-end performance chipset for Intel®
Xeon® processors supports dual processing, an 800 MHz
system bus (6.4 GB/sec bandwidth) and a dual-channel
DDR2 400 MHz SDRAM memory subsystem, putting
increased power and efficiency behind demanding
Expand to meet your performance and storage needs
Supporting up to five internal HDD, three optical disks,
two PCIe, three PCI-X (1 x 133 MHz and 2 x 100 MHz),
and 2 PCI slots, the HP xw8200 provides the hard disk
space and performance needed for large models and
storage-intensive projects.
Handle very large and complex data sets
The HP xw8200 implements 8 memory DIMM slots. With
2 GB DIMMs, the HP xw8200 can achieve the largest
memory configuration supported by the Intel E7525
chipset - 16 GB on Linux and the Microsoft Windows XP
Professional x64 Edition.
Enable advanced, high-perfomance visualization
The PCIe x16 graphics interface provides 4x the total
peak bandwidth and 2x the unidirection bandwidth of
AGP 8X graphics. HP workstations offer a wide range of
graphics choices for applications that are fully supported
on the HP xw8200 platform.
Custom configure your workstation
HP Performance Tuning Framework, available on HP
workstations with Microsoft® Windows®, will guide your
setup, allowing a “custom” configuration that best
matches the workstation to user requirements. This
customization facilitates availability of the latest graphics
drivers and removes some memory constraints.
Click here for manufacturer specifications
