HPE Aruba Silver Peak EC-XL-H R8L30A 10 Bay 2x PSU 6x SFP28 SD-WAN Gateway

HPE Aruba Silver Peak EC-XL-H R8L30A 10 Bay 2x PSU 6x SFP28 SD-WAN Gateway

Condition New



Compeve SKU 101000350701



Specifications



PN

EC-XL-H

JZ881A

500642-004

R8L30A

HSTNS-2154

201756-001



WAN bandwidth capacity (all features +encryption)

2 to 10 Gbps (bidirectional)

Simultaneous connections 2,000,000

Recommended WAN optimization up to 5 Gbps



Power supplies Dual redundant



Network

Six ports supporting any combination of WAN and LAN including support

for up to 64 802.1q VLANs; WAN link redundancy supported through business

intent overlays with multiple link bonding options; LAN‑side protection

includes VRRP and BGP; Multiple IPSLA options included



Storage

HPE Aruba Networking EdgeConnect SD‑WAN Operating System: 960 GB SSD,

network memory



Network Memory 3.2 TB NVMe

Routing BGP and OSPF supported

MTBF Greater than 10 years



Disk encryption 128‑bit AES

Network encryption (data plane) IPSec (256‑bit AES)

Network encryption (management plane) TLS 1.2



LAN/WAN Ethernet

SKU JZ881A–6x 1/10 Gbps SFP+ or 10/25 Gbps SFP28 transceiver cages

as per IEEE 802.3z, 802.3ae, 802.1Q, 802.3by, 802.3cc

SKU S0B67A–6x 1/10 Gbps SFP+ transceiver cages

as per IEEE 802.3z, 802.3ae, 802.1Q



Management 2x 10/100/1000; console port



Power adapter 1+1 redundant, AC



CLI

Full‑featured CLI available over console port or SSH



GUI

HPE Aruba Networking EdgeConnect SD‑WAN Operating System includes a

web user interface (WebUI), which manages an individual appliance.

HPE Aruba Networking SD‑WAN Orchestrator provides centralized configuration,

monitoring, and management of multiple HPE Aruba Networking EdgeConnect

SD‑WAN appliances.



API

REST API at appliance level; HPE Aruba Networking SD‑WAN Orchestrator provides REST API for

systems integration.



SNMP

SNMPv2c, SNMPv3



Secure access

SSH and HTTPS (WebUI), supports PKI as per RFC 5280, RFC 6960, and RFC 7030



Logging Secure

syslog with configurable levels



Authentication

Local database, RADIUS, TACACS+



Statistics

Graphing and monitoring, real time and historical; NetFlow and IPFIX supported
