Condition New
Compeve SKU 101000350701
Specifications
SFP28 (Small Form Factor Pluggable) supports: SFI interfaces supports 25GBase-R PCS and 25 Gigabit PMA in order to connect with SFP28 to 25GBase-SR
25GBase-SR SFP28:
IEEE Standard / Network topology: Fiber 25Gigabit Ethernet, 25GBASE-SR (850nM LAN PHY).
25GBase-SR SFP28:
Data Transfer Rate : 25.78125Gbps
25GBase-LR SFP28:
IEEE Standard / Network topology: Fiber 25Gigabit Ethernet, 25GBASE-LR (1310nM LAN PHY)
25GBase-LR SFP28:
Data Transfer Rate: 25.78125Gbps
25GBase-LR SFP28:
Cables and Operating distance Up to: Single-Mode: 10000m at 9um
Interface Standard: PCI-Express Base Specification Revision 3.0 ( 8 GTs)
Board Size: Low profile short add-in card: 145.542mm X 64.389mm (5.730”X 2.535”)
PCI Express Card Type: X8 Lane
On Board Connector Voltage +12V +/-8%
PCI Connector: X8 Lane
Controllers: Intel XXV710-AM2
Holder: Metal Bracket
Weight: 340gr (12 oz)
Power Consumption (25G-SR) 9.84W, 0.82A at 12V: Typical all ports operate at 25Gb/s,
6.84W, 0.57A at 12V: Typical No link at all ports
Power Consumption (25G-LR) 10.32W, 0.86A at 12V: Typical all ports operate at 25Gb/s,
5.76W, 0.48A at 12V: Typical No link at all ports
Power Consumption (10G-SR) 6.84W, 0.57A at 12V: Typical all ports operate at 10Gb/s,
5.76W, 0.48A at 12V: Typical No link at all ports
Power Consumption (10G-LR) 6.96W, 0.58A at 12V: Typical all ports operate at 10Gb/s,
6.00W, 0.50A at 12V: Typical No link at all ports
Power Consumption (25G-DA) 8.16W, 0.68A at 12V: Typical all ports operate at 25Gb/s,
4.32W, 0.36A at 12V: Typical No link at all ports
Power Consumption (10G-DA) 5.52W, 0.46A at 12V: Typical all ports operate at 10Gb/s,
4.32W, 0.36A at 12V: Typical No link at all ports
Operating Temperature: 0°C – 45°C (32°F – 113F)
Air Flow Requirements: 200 ft./min
SRIOV Capable: Yes
Storage: -40°C–65°C (-40°F–149°F)
Compeve DTP#: mrk001
